CuBe2NiTi Beryllium Copper Strip Coil 0.3x250mm Polished

Place of Origin China
Brand Name CUBERYLLIUM
Certification ISO,SGS
Model Number Qbe1.9-CuBe2NiTi
Minimum Order Quantity 50
Price 30USD
Packaging Details in coil packed into wooden case
Delivery Time 10~15days
Payment Terms L/C, T/T, Western Union
Supply Ability 200T/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Ageing(Soft) Beryllium Bronze Strip Coil Max Coil Wt. 2T
Thinnest Thick. 0.02mm Max Width 305mm
Length 200mm, 500mm, 1000mm Or As Required Standard ГОСТ 1789-70
Safe Handling No Special Health Risk. Machining Property Good
Surface Bright/Polished Flatness Good
State Soft, Hard, Ageing(Soft), Ageing(Hard) Typical Application For Electronic Connectors
Available Shapes Strip, Sheet
High Light

CuBe2NiTi Beryllium Copper Strip

,

Electronic Connectors Beryllium Copper Strip

,

Beryllium Copper Strip Polished

Leave a Message
Product Description

CuBe2NiTi Beryllium Copper Strip Coil 0.3x250mm HV>170 For Europe Market

CUBERYLLIUM Brande QBe1.9 Ageing(Soft) Beryllium Bronze Strip Coil For Electronic Connectors

Product Description:

Name: Ageing(Soft) Beryllium Bronze Strip Coil

Tape: Qbe1.9

Specification: 0.8mmx200mm

Tolerance: +/-0.015mm

State: Soft, Hard, Ageing(Soft), Ageing(Hard)

Surface: Bright/Polished

Application: For Electronic Connectors



Product Informance of CUBERYLLIUM® Company:

CUBERYLLIUM® manufactures copper beryllium in several distinct compositions. These fall into two categories: alloys selected for high strength (Alloys 172,173,170) and alloys selected for high conductivity (Alloys 751,750,741). And Gost standard QBe2,QBe1.9Ti(БрБ2;БрБНТ1.9) for Russia Market. Also Supply Master alloy : CuBeryllium-200; CuBeryllium-275);CuBeryllium-350 and Cuberyllium-400 to global factory.



CUBERYLLIUM ®-Qbe1.9 also named Cube1.9Ti. Qbe1.9 alloy contains appr.Ti 0.1~0.25% of Ti, has small elastic delay, small elastic hysteresis, high fatigue strength, stable elasticity when temperature changes, etc. The property compared with other beryllium copper alloys, Qbe1.9 alloy attains the highest strength and hardness of any commercial copper base alloy at age hardened condition. It is widely used in China military project.



Chemical Composition of Qbe1.9 Beryllium Bronze Alloy:

CUBERYLLIUM® Brand

Gost-

Number

Be Al Ni Fe Cu Si Ti
Qbe1.9Ti БрБНТ1.9 1.87-2.10 0.15 max 0.2~0.5

0.15

max

Balance

0.15

max

0.1~0.25



Typical Physical Properties of Qbe1.9 Beryllium Bronze Alloy:
Density (g/cm3): 8.25
Elastic Modulus(Gpa): 130
Electrical Conductivity: 22-28% IACS
Thermal Expansion Coefficient(m/m℃): 17.5x10-6

Thermal Conductivity(25℃): 105W/m℃
Melting Point (°C): 870



Mechanical And Electrical Properties of Qbe1.9 Beryllium Bronze Strip:

Name Temper Thickness
(mm)
Tensile Strength Hardness Elongation (min)
MPa HV Percent
Qbe1.9 Soft <0.15 >390 <120 >30%
0.15~0.25 390~590
>0.25 390~590
Hard <0.15 >590 >160 >3%
0.15~0.25 590~880
>0.25 640~930
After Ageing
(Soft)
<0.15 >1080 >330 >2%
0.15~0.25 1080~1470
>0.25 1130~1470
After Ageing
(Hard)
<0.15 >1080 >360 >1.5%
0.15~0.25 1130~1570
>0.25 1170~1570



Shape Available:

Cold Rolled Hot Worked
Strip Rod&Bar
Round Bar Plate
Square Bar Tube
Sheet



Key Technology of Beryllium Copper(Heat treatment)

Heat treatment is the most important process for this alloy system. While all copper alloys are hardenable by cold working, beryllium copper is unique in being hardenable by a simple low temperature thermal treatment. It involves two basic steps. The first is called solution annealing and the second, precipitation or age hardening.

Solution Annealing

For the typical alloy CuBe1.9 Ti(1.85- 2.1%) the alloy is heated between 720°C and 860°C. At this point the contained beryllium is essentially “dissolved” in the copper matrix (alpha phase). By rapidly quenching to room temperature this solid solution structure is retained. The material at this stage is very soft and ductile and can be readily cold worked by drawing, forming rolling, or cold heading. The solution annealing operation is part of the process at the mill and is not typically used by the customer. Temperature, time at temperature, quench rate, grain size, and hardness are all very critical parameters and are tightly controlled by Cuberyllium.

Age Hardening

Age hardening significantly enhances the material’s strength. This reaction is generally carried out at temperatures between 260°C and 540°C depending on alloy and desired characteristics. This cycle causes the dissolved beryllium to precipitate as a beryllium rich (gamma) phase in the matrix and at the grain boundaries. It is the formation of this precipitate which causes the large increase in material strength. The level of mechanical properties attained is determined by the temperature and time at temperature. It should be recognized that beryllium copper has no room temperature aging characteristics.



Product Photo:

CuBe2NiTi Beryllium Copper Strip Coil 0.3x250mm Polished 0



FAQ:

Q1: Could you produce Beryllium Copper strip by Mill Hardened process.
A1: Yes, we could produce AM(TM00), 1/2HM(TM01).HM(TM04) XHM(TM06) XHMS(TM08).,we are the only factory could do harden strip in China.

Q2: What’s the advantages the Beryllium Copper of CUBERYLLIUM®.
A2: 1: The Biggest Coil weight could be reach 1200kg/Coil

2: We are the only one who melting by Vacuum semi-Continuous Furnace.

3: Surface further polishing for top clients.

Q3: Why you melting by Vacuum semi-Continuous Furnace.
A3: Could be get the Cast ingot without gas,smaller segregation, Grain Refinement

Q4: What's the payment terms?
A4: We accept T/T, L/C, Paypal etc. It can be negotiated when the amount is different.
